Wheel Offset Harrows 10.5in Spacing
Call for Pricing
Price
Make:
Amco Manufacturing Inc
Model:
Wheel Offset Harrows 10.5in Spacing
Category:
Amco-Manufacturing-equipment, New, Wheel Offset Harrows
Model J41
| Model | Cutting Width | No. of Disc Blades | No. of Bearings | Approx. Engine HP Required | Approx. Weight lbs* |
|---|---|---|---|---|---|
| J41-1624 | 7’0″ | 16 | 6 | 68-88 | 2,592 |
| J41-1824 | 7’10” | 18 | 6 | 74-95 | 2,739 |
| J41-2024 | 8’8″ | 20 | 6 | 81-101 | 2,905 |
| J41-2224 | 9’6″ | 22 | 8 | 88-108 | 3,154 |
| J41-2424 | 10’4″ | 24 | 8 | 95-115 | 3,345 |
Model J42
50″ Main Frame
| Model | Cutting Width | No. of Disc Blades | No. of Bearings | Approx. Engine HP Required | Approx. Weight lbs* |
|---|---|---|---|---|---|
| J42-2024 | 8’8″ | 20 | 6 | 101-128 | 3,937 |
| J42-2424 | 10’4″ | 24 | 8 | 122-162 | 4,614 |
| J42-2824 | 12’0″ | 28 | 10 | 135-176 | 5,037 |
86″ Main Frame
| Model | Cutting Width | No. of Disc Blades | No. of Bearings | Approx. Engine HP Required | Approx. Weight lbs* |
|---|---|---|---|---|---|
| J42B-2824 | 12’0″ | 28 | 10 | 149-189 | 6,063 |
| J42B-3224 | 13’8″ | 32 | 12 | 169-203 | 6,558 |
| J42B-3624 | 15’4″ | 36 | 12 | 189-236 | 6,910 |
| J42B-4024 | 17’0″ | 40 | 12 | 216-257 | 7,803 |
| J42B-4424** | 18’8″ | 44 | 16 | 236-277 | 8,389 |
| J42B-4824** | 20’6″ | 48 | 16 | 257-297 | 8,741 |
Model J43
50″ Main Frame
| Model | Cutting Width | No. of Disc Blades | No. of Bearings | Approx. Engine HP Required | Approx. Weight lbs* |
|---|---|---|---|---|---|
| J43-2024 | 8’8″ | 20 | 6 | 115-135 | 4,303 |
| J43-2424 | 10’4″ | 24 | 8 | 122-162 | 5,036 |
| J43-2824 | 12’0″ | 28 | 10 | 149-189 | 5,617 |
86″ Main Frame
| Model | Cutting Width | No. of Disc Blades | No. of Bearings | Approx. Engine HP Required | Approx. Weight lbs* |
|---|---|---|---|---|---|
| J43B-2824 | 12’0″ | 28 | 10 | 162-203 | 6,616 |
| J43B-3224 | 13’8″ | 32 | 12 | 176-230 | 7,213 |
| J43B-3624 | 15’4″ | 36 | 12 | 189-243 | 8,074 |
| J43B-4024** | 17’0″ | 40 | 12 | 216-270 | 8,533 |
| J43B-4424** | 18’8″ | 44 | 16 | 243-304 | 9,283 |
Model J44
50″ Main Frame
| Model | Cutting Width | No. of Disc Blades | No. of Bearings | Approx. Engine HP Required | Approx. Weight lbs* |
|---|---|---|---|---|---|
| J44-2024 | 8’8″ | 20 | 6 | 128-162 | 4,464 |
| J44-2424 | 10’4″ | 24 | 8 | 149-176 | 5,222 |
86″ Main Frame
| Model | Cutting Width | No. of Disc Blades | No. of Bearings | Approx. Engine HP Required | Approx. Weight lbs* |
|---|---|---|---|---|---|
| J44B-2824 | 12’0″ | 28 | 10 | 162-216 | 6,848 |
| J44B-3224 | 13’8″ | 32 | 12 | 176-230 | 7,467 |
| J44B-3624 | 15’4″ | 36 | 12 | 189-243 | 8,406 |
| J44B-4024** | 17’0″ | 40 | 16 | 216-270 | 9,221 |
| J44B-4424** | 18’8″ | 44 | 16 | 243-304 | 9,626 |
