<ul>
<li>Hitch can be set to meet disking needs</li>
<li>Choice of disk blades provided</li>
<li>Gang wrenches come as base equipment</li>
<li>One-piece welded mainframe</li>
</ul>


225 Offset Disk

Agriculture

<ul>
<li>1,600-gallon (6,057 L) tank</li>
<li>Up to 132-foot (40.23 m) boom</li>
<li>375 hp, 9.0 L engine</li>
<li>35 mph (56.3 km/h) transport speed</li>
</ul>


616R Sprayer

<ul>
<li>Pull-type unit with drawbar</li>
<li>Adjustable discharge chute</li>
<li>Reversible, hydraulic feed roll</li>
</ul>


WC12 Series Wood Chippers

<ul>
<li>Adjustable blade scrapers increase productivity</li>
<li>Notched or smooth disk blades available in two sizes</li>
<li>Durable Clevis hitch</li>
<li>Oil bath tapered roller bearings minimize maintenance</li>
</ul>


DH52 Series Offset Disks

<ul>
<li>Forged-steel bale spear tines</li>
<li>Hitch provides a super-quick connection</li>
<li>Tubular frame is built strong&nbsp;</li>
</ul>


HS20 Series 3-Point Hitch Bale Spears

<div>
<ul>
<li>Cover more acres per day with less stress by extending AutoTrac into post emerge in-field operations such as spraying and harvest.</li>
<li>Protect crop yield when applying crop protectants and nutrients in stand crop by making sure that the sprayer or tractor stays off of the crop rows.</li>
<li>Focus on quality of the job being performed and ensure that the machine is operating as it should rather than being concerned about steering the machine in standing crop.</li>
</ul>
</div>


AutoTrac™ RowSense™ AutoTrac™ RowSense™ (Available on Combines, Sprayers and Tractors)

<ul>
<li>15 ft. cutting width</li>
<li>540 or 1000 PTO RPM</li>
<li>Front and rear suspension options</li>
<li>Inward or outward rotation</li>
</ul>


FC15M Flex Wing Rotary Cutter

<ul>
<li>200 or 300 cu. ft. (5.6 or 8.5 m3)dry box </li>
<li>375 hp, 9.0 L engine</li>
<li>25 mph (40.2 km/h) field speed, 35 mph (56.3 km/h) transport</li>
<li>Integrated intelligence with StarFire™ receiver, JDLink™ connection, and more</li>
<li>Three cab and visibility packages to customize your sprayer</li>
</ul>


600R Dry Spinner Spreader

<ul>
<li>A proven design that drives the cutting unit with electric reel motors</li>
<li>102 potential leak points eliminated in the reel circuit</li>
<li>Reduced sound levels and fuel consumption @ 2250 RPM</li>
<li>Greatly reduce triplex ring with exclusive offset cutting units</li>
</ul>


2550 E-Cut™ Hybrid Diesel Triplex Mower

<ul>
<li>Heavy-duty knife drive and cutterbar for increased reliability</li>
<li>Heavy-duty multi-bat reel improves crop flow</li>
<li>Adjustable reel-cam track to control crop release</li>
<li>Header index ensures optimum platform speeds</li>
</ul>


1100A Auger Platform

<ul>
<li>Digidrive<sup>TM</sup> drive system ensures maximum life</li>
<li>Hydraulic working angle adjustment</li>
<li>Durable Steel tines</li>
<li>Balloon tires operates smoothly on bumpy ground</li>
</ul>


TD13 Series Hay Tedder

Disks

<ul>
<li>Adjustable disk blade scrapers increase productivity</li>
<li>Notched or smooth disk blades available in two sizes</li>
<li>Durable clevis hitch</li>
<li>Oil bath tapered roller bearings minimize maintenance</li>
</ul>


DH51 Series Offset Disks

<ul>
<li>Adjustable disk blade scrapers</li>
<li>Disk blades (notched or smooth) available in two sizes</li>
<li>Rear hitch for attaching additional implement</li>
<li>Oil bath tapered roller bearings minimize maintenance</li>
</ul>


DH52F Series Folding Offset Disks

<ul>
<li>Adjustable disk blade scrapers</li>
<li>Rear hitch for attaching additional implement</li>
<li>Transport locks secure disk wings</li>
<li>Oil bath tapered roller bearings minimize maintenance</li>
</ul>


DH53 Series Offset Disks

John Deere

<ul>
<li>Net Power: 200 kW (268 hp) at 1,900 rpm</li>
<li>Pump Capacities: 210 cm<sup>3</sup> (13 cu. in.) / 180 cm<sup>3</sup> (11 cu. in.)</li>
<li>Boom Reach: 8.6 m (28.2 ft.) / 10 m (32.8 ft.) / 11.0 m (36.1 ft.)</li>
</ul>


1470G Wheeled Harvester

<ul>
<li>Net Power: 131 kW (178 hp) at 1,900 rpm</li>
<li>Boom Reach: 8.5 m (27.9 ft.) / 10 m (32.8 ft.)</li>
<li>Tractive Force: 150 kN (33,721 lbf) with 24.5 tires/ 160 kN (35,969 lbf.) with 26.5 tires.</li>
<li>Load Rating: 11 000 kg (24,251 lb.)</li>
</ul>


1010G Forwarder

Offset Disks

Tillage Equipment

<ul>
<li>Moldboard frame pivots with the bottoms</li>
<li>Safety-trip standards available to save time</li>
<li>Plastic moldboard and steel shins</li>
<li>Rear gauge wheel</li>
</ul>


975 Reversible Plow

<ul>
<li>Break up and evenly spread straw residue</li>
<li>Work at speeds up to 12 mph (19.3 km/h)</li>
<li>Drop-out tine replacement for easy maintenance</li>
<li>Flexible sections maintain even ground contact </li>
</ul>


HH70 HH70 Heavy Harrow Tillage Tools

<ul>
<li>High clearance handles heavy residue levels</li>
<li>Coulter mounting arms</li>
<li>Operator&#8217;s manual storage container</li>
<li>Shear-bolt coulters suited for areas without rocks</li>
</ul>


3710 Moldboard Plow

<ul>
<li>Variety of working widths available</li>
<li>Mainframe extensions</li>
<li>Setback brackets for staggered standard pattern</li>
<li>3/4-in. straight shear-bolt standard minimizes soil and residue disturbance</li>
</ul>


2100 Minimum Till Ripper

<ul>
<li>Offers a variety of sizes</li>
<li>Implement warning lights enable safe transport</li>
<li>Shovels and attaching hardware</li>
<li>Sweeps and attaching hardware</li>
</ul>


610 Integral Chisel Plow

HH82 HH82 Heavy Harrow Tillage Tools

<ul>
<li>Moldboard frame pivots with the bottoms</li>
<li>Plastic moldboard and steel shins</li>
<li>Landsides with wedges</li>
<li>Front gauge wheels</li>
</ul>


995 Reversible Plow

<ul>
<li>Perfect for light to medium soils, seedbed prep</li>
<li>Features John Deere&nbsp;TruSet™ Tillage Technology</li>
<li>Radial Tire Option</li>
<li>Knife-edge Rolling Basket</li>
<li>Extended-Life Bearing</li>
</ul>


2630 Three- and Five-Section Tandem Disks

View Product Brochure

<p>Harvesting equipment, cutters, shredders, hay &amp; forage equipment, planting &amp; seeding equipment, sprayers and tillage equipment</p>


BALR: Farm Equipment

<div>

       <p>The hitch can be set to work directly behind the tractor or offset to the right or left, which is ideal for orchards or vineyards.</p>
       <p> </p>
       <p>Moving the tongue on the hitch bar (1) provides a course adjustment.</p>
       <p> </p>
       <p>Changing the angle of the hitch tongue, through a series of holes (2), fine-tunes adjustments.</p>
       <p> </p>
       <p>The clevis (3) can be assembled so a disk harrow can be used with tractors having either a straight or open-type drawbar.</p>
       <p> </p>
       <p>A safety chain and hose support are included in base equipment.</p>
      </div>

Hitch can be set to meet disking needs

<div>
       <h5>Blade spacing</h5>

       <p>The 225 Disk is available in 229-mm (9-in.) blade spacing, and the 425 Disk is available with 229-mm (9-in.) or 279-mm (11-in.) blade spacing.</p>
       <p> </p>
       <p>Blade spacing recommendations for best performance are as follows:</p>
       <p> </p>
       <p>
       </p><table bordercolor="#000000" cellspacing="2" cellpadding="2" width="0%" border="1">
        <tbody>
         <tr>
          <td><p align="center"><strong>229-mm (9-in.) spacing</strong></p></td>
          <td><p align="center"><strong>279-mm (11-in.) spacing</strong></p></td>
         </tr>
         <tr>
          <td>Seedbed preparation</td>
          <td>All primary tillage</td>
         </tr>
         <tr>
          <td>Chemical incorporation </td>
          <td>Heavy residue conditions</td>
         </tr>
         <tr>
          <td>Light primary tillage</td>
          <td>  </td>
         </tr>
         <tr>
          <td>Average residue levels</td>
          <td>  </td>
         </tr>
        </tbody>
       </table>
       <h5>Blade choices</h5>

       <p>Cone-type or spherical blades are available in a variety of sizes with a solid or cutout design.</p>
       <ul>
        <li>559-mm (22-in.) or 610-mm (24-in.) diameter solid or cutout design on 225 Disk</li>
        <li>610-mm (24-in.) or 661-mm (26-in.) diameter solid or cutout design on 425 Disk</li>
       </ul>
       <h5>Blade tapers and furrow filler</h5>

       <p>Right rear gang is tapered and includes two smaller disks to feather the soil.</p>
       <p> </p>
       <p>
       </p><table bordercolor="#000000" cellspacing="2" cellpadding="2" width="0%" border="1">
        <tbody>
         <tr>
          <td>Blade size (diameter)</td>
          <td>Blade taper size (diameter)</td>
         </tr>
         <tr>
          <td>559 mm (22 in.)</td>
          <td>One 508 mm (20 in.) and one 457 mm (18 in.)</td>
         </tr>
         <tr>
          <td>610 mm (24 in.)</td>
          <td>One 559 mm (22 in.) and one 508 mm (20 in.)</td>
         </tr>
         <tr>
          <td>661 mm (26 in.)</td>
          <td>One 610 mm (24 in.) and one 559 mm (22 in.)</td>
         </tr>
        </tbody>
       </table>

       <p>A 356-mm (14-in.) diameter furrow filler (arrow) is available to further smooth and level the soil.</p>
       <p> </p>
       <p>A scraper is included with the furrow filler.</p>
      </div>

Choice of disk blades enables operators to match the disk to the job

<div>

       <p>The mainframe on 225 and 425 Offset Disks is made of one-piece, heavy, structural steel tubing to resist torsional forces on the frame:</p>
       <ul>
        <li>102 mm x 102 mm x 5 mm (4 in. x 4 in. x 3/16 in.) on the 225 Offset Disk</li>
        <li>76 mm x 127 mm x 10 mm (3 in. x 5 in. x 3/8 in.) on the 425 Offset Disk</li>
       </ul>
      </div>

225 Offset Disk
